Case Summary 🔎

Patient Information

• Chief Complaint(C.C): The patient reported discomfort in the lower right area.

• Diagnosis: Fixture removal and re-implantation in sites #45, #46, and #47 due to peri-implantitis

Treatment Plan

• Guided Bone Regeneration(GBR) using the CTi-mem

• Delayed implant placement

• Final prosthetic restoration

Results

• The GBR procedure at sites #45, #46, and #47 was successful, enabling implant placement and final prosthetic restoration.

• Before & After

Before

After

Before

After

Products Used

• Neo GBR Kit & CTi-mem



Case Presentation

1️⃣ Pre-Op

The patient presented with peri-implantitis at sites #45, #46, and #47, necessitating the removal of the existing fixtures.

• #45, #46, #47 Peri-implantitis



• #45, #46, #47 Fixture removal







2️⃣ 1st Surgery - Guided Bone Regeneration(GBR)

• After opening the flap, it was observed that the bone width is narrow, and there is considerable vertical bone loss.

•



  To increase the vertical height, Ez-fixing screws were inserted.

•

  A bone graft was performed by combining autograft collected with the ACM (Autobone Chip Maker) and bovine bone (Regenoss).



• Layering with DM bone (allograft)



• Contoured the titanium membrane(CTi-mem) to cover

•

  A collagen membrane used for coverage

•

  Interrupted suture



3️⃣ 2nd Surgery - Implant Placement

• Returned after 1 year and 3 months due to patient's personal reasons



• Performed flap opening



• Membrane removal





• Ez-fixing screw removal





• Bone collected for biopsy





• IT wide neck 5.0X10 implant placement, bone quality D111 and ITV 60→40N





• Alloplast added at the collection site and suture





• Biopsy examination shows satisfactory bone formation



4️⃣ Post-Op

• Post-Op Panorama



5️⃣ Final Prosthetics

• 5-month follow-up after final restoration







6️⃣ Clinical Video

💡 Explore the comprehensive surgical procedure in the video below to gain a deeper understanding.
